Medium Duty Longspan Shelving
Load Capacity: 300~600kg/level.
To store cartons, boxes, plastic pins, documents.
Standard Height: H2000mm, H2500mm, H3000mm.
Products Description
Medium Duty Longspan Shelving is a manually loaded warehouse storage system for cartons, plastic bins, documents, spare parts and other medium-weight goods. Wider shelf spans provide more usable storage space than conventional light-duty shelving while remaining accessible without forklifts.
Unistar’s standard longspan shelving range supports 300–600 kg per level and is available in several standard heights, lengths, depths and shelf quantities.
Standard Medium Duty Longspan Shelving Range
| Parameter | Available Range |
|---|---|
| Load capacity | 300–600 kg per level |
| Heights | 2,000 / 2,500 / 3,000 mm |
| Lengths | 1,200 / 1,500 / 1,800 / 2,000 mm |
| Depths | 400 / 500 / 600 mm |
| Shelf levels | 4 / 5 / 6 levels |
| Color option 1 | Blue frames with orange beams and shelves |
| Color option 2 | Grey frames, beams and shelves |
Suitable Storage Applications of Medium Duty Longspan Shelving
Cartons and packaged goods
Plastic storage bins
Automotive and machinery parts
Tools and maintenance supplies
Archive boxes and documents
Retail and wholesale inventory
E-commerce picking stock
Workshop consumables
Selection Notes of Medium Duty Longspan Shelving
Published capacity refers to a uniformly distributed load.
Longer shelf spans may require a different beam profile.
Shelf height should match manual picking requirements.
Shelf depth should provide full support without excessive product overhang.
Additional levels increase storage capacity but reduce vertical clearance.
The number of starter and add-on bays should be based on the complete row layout.
Decking material must be selected according to the stored goods.
